Newton Labs PL4000UW Pipeline Underwater Laser Scanner Newton Labs PL4000UW Newton Labs

4000 Meter Depth Rated Underwater Laser Scanner with easy MUX and IMU Integration  -  10 Meter Range

The M4000UW underwater laser scanner operates by optical triangulation. The projected laser line sweeps the target surface and the high-resolution camera, centered on the target, captures any deformation of the line and sends the information to the surface laptop or control console where the Newton-developed algorithms create and record a point cloud, enabling precise, post-session dimensioning using industry standard three-dimensional software.

  • IMU and MUX Integration  The M4000UW easily integrates with any MUX and IMU devices for power, communication and position data. The PL4000UW only requires 24VDC at less than 1 Amp and GigEthernet from the MUX on the ROV/AUV. Extremely low power for AUV usage.
  • Live Camera View  The M4000UW, unlike other underwater laser scanners, contains a live operator camera view that greatly simplifies scanning, shortens scanning time and increases accuracy.
  • Extremely High Accuracy  With a longer base line and higher resolution camera than any other underwater laser scanner, the PL4000UW has the highest accuracy in the industry.
  • No Operating Components Exposed to the Water  The M4000UW is designed with all operating components fully contained behind the pressure boundaries.
  • Designed for Easy ROV/AUV Mounting  The M4000UW requires only GigEthernet and 24VDC from the ROV/AUV at a very low current draw. Convenient mounting pedestals and mounting pads allow for simple gripping or bolting to any ROV/AUV.
  • Scan Area  The M4000UW has a scan area of 8.4 Meters by 6.7 Meters at 10 Meters distance from the scanned objects.
  • CAD Model Resolution  The M4000UW produces scans with CAD resolutions down to 0.02MM depending on the distance from the scanned object, IMU update rate and the speed of travel.
  • All Digital Data  All data is transmitted to the surface or the AUV vis GigEthernet for permanent storage and later analysis.
  • SS Construction  300 Series Stainless Steel.
  • Streamlinded Design  For low current drag.



Newton Labs developed and manufactures the PL4000UW Underwater Laser Scanner specifically to gather highly-accurate non-contact measurements in subsea environments.
